Beyond Van der Waals: The Rise of Hydrogen-Bonded MXene Superlattices

The New Frontier in 2D Materials

While traditional superlattice research has focused on van der Waals materials, a groundbreaking development from recent Nature research reveals a new class of non-van der Waals superlattices that could revolutionize materials science. These innovative structures, composed of transition metal carbides and carbonitrides (MXenes), leverage hydrogen bonding instead of weak van der Waals forces, creating unprecedented opportunities for electronic and energy applications.

Understanding the Superlattice Evolution

Traditional artificial superlattices have typically fallen into two categories: moiré superlattices and heterostructure superlattices. Moiré superlattices have demonstrated remarkable phenomena including superconductivity, ferromagnetism, and correlated insulating states. Heterostructure superlattices, involving periodic arrangements of alternating atomic layers, have shown promising electrical and magnetic properties. However, both approaches have faced limitations due to their reliance on van der Waals materials and the associated challenges with interface coupling and material availability., according to industry developments

The conventional manufacturing methods—mechanical exfoliation or chemical vapor deposition—while effective for creating ideal superlattice models, suffer from limited yield and reproducibility due to their manual transfer processes and multiple steps. Even advanced techniques like molecular beam epitaxy or metal-organic CVD, though offering better control over compositions and crystal orientation, still grapple with the fundamental constraints of van der Waals sources., according to emerging trends

The MXene Breakthrough

The research team developed an innovative approach using MXenes derived from MAX phases (where M represents an early transition metal, A denotes an element from groups 13-16, and X is C and/or N). Their method employs a stiffness-mediated rolling-up strategy that fundamentally differs from previous approaches.

This technique involves customizing the bending stiffness of MXene atomic layers by creating transition metal vacancies in MX slabs. When introduced to specific exfoliation agents with bulky size and low surface tension, these modified layers undergo rapid delamination and flexural deformation, triggering an ordered rolling-up process that transforms two-dimensional sheets into one-dimensional structures., according to expert analysis

The Manufacturing Process Revealed

Using a vanadium-based MAX phase (VAlC) as a model precursor, researchers produced multilayer MXene (VCT) through an in situ HF etching procedure with variable valence states of vanadium. The critical transformation occurred when introducing multilayer MXene into an aqueous dispersion of tetrabutylphosphonium hydroxide (TBPH), which features a large size of 13.6 Å and low surface tension of 32.2 mN m.

The results were remarkable: MXene layers delaminated and rolled up in just 0.3 seconds, with approximately 96% of the material undergoing layer-by-layer rolling up to form one-dimensional structures with ordered arrangements. These structures demonstrated excellent monodispersity in aqueous suspension due to their negative zeta potential.

Structural Characteristics and Analysis

Transmission electron microscopy revealed that the resulting one-dimensional roll-ups possessed end-open structures with diameters ranging from 20 nm to 100 nm and length-diameter aspect ratios of 10-50. Each roll-up formed through spiral wrapping of a single atomic layer with identifiable starting and ending layers, maintaining a constant interlayer spacing of approximately 1.14 nm.

Theoretical calculations confirmed that low bending stiffness facilitates flexural deformation of atomic layers, promoting roll-up formation. By introducing active species such as vanadium and nitrogen into titanium-, niobium-, and tantalum-based MX slabs to form solid-solution states, researchers enhanced etching activities and generated more vacancies, further reducing bending stiffness and facilitating roll-up formation.

Non-van der Waals Superlattice Confirmation

Through detailed TEM and selected-area electron diffraction analysis, researchers identified a crucial structural feature: an included angle between two edges of single roll-ups ranging from 0.1° to 8.2°, indicating non-ideal cylindrical roll-up structures. The observation of two sets of identical hexagonal diffraction spots with a twist angle demonstrated periodic arrangement consistent with moiré superlattice models.

Unlike typical van der Waals moiré superlattices that lack dangling bonds, these VCT moiré superlattices contain abundant dangling bonds such as -OH and =O, creating significant hydrogen bonding between layers. Fourier transform infrared spectra confirmed these strong hydrogen bonds, distinguishing them from weak van der Waals interactions and justifying their classification as non-van der Waals superlattices.

Enhanced Electronic Properties

Ultraviolet photoelectron spectroscopy measurements revealed enhanced electronic density of states at the Fermi level in VCT non-van der Waals superlattices, suggesting that the hydrogen-bonded superlattice structure improves electronic coupling capacities. Density functional theory calculations of differential charge density further indicated that the introduced moiré potential could form interlayer conduction channels, potentially enhancing electron transport.

The research team successfully produced 17 different MXene roll-ups based on vanadium, titanium, niobium, and tantalum transition metal carbides and carbonitrides, creating a rich material platform with variable compositions and crystal structures for fundamental studies and practical applications., as covered previously

Implications for Future Technologies

This development in non-van der Waals superlattices opens new possibilities for advanced electronics, energy storage, and quantum materials. The strong hydrogen bonding interface coupling, combined with tunable electronic properties, positions these materials as promising candidates for next-generation devices that require robust interfacial interactions and enhanced charge transport capabilities.

The stiffness-mediated rolling-up strategy represents a scalable alternative to traditional superlattice fabrication methods, potentially enabling mass production of these sophisticated structures for commercial applications. As research continues, these hydrogen-bonded MXene superlattices may unlock new physical phenomena and functional properties beyond what’s achievable with conventional van der Waals materials.
